Unique Designed Manual Tilt Rotation Stage Six Axis CE Manual Goniometric Stage
SA1603 Unique Designed Six Axis Manual Tilt Rotation Stage Table And Manual Goniometric Stage
SA1603 Unique Designed Six Axis Manual Tilt Rotation Stage Table And Manual Goniometric Stage
Support the motion of any point around a point in space;
Support any point in the space to execute any path trajectory motion:
Supports uniform track speed, variable speed, track linkage with IO, etc.
Global absolute accuracy after calibration: 6μm
HXC has many different specifications manual translation(linear) stage, including manual stage, linear stage, translation stage, Z axis lifting platform,Lab Jack,High-Load Vertical Stages, 360 degree rotation stage,Rotary Stage,Angle adjustment stage and so on.
| Specification parameters | SA1603 | ||
| Driving and mechanical characteristic(mm) | X | Y | Z |
| Effective travel(mm) | 60 | 30 | 30 |
| straightness(μm) | 3 | 3 | 3 |
| Maximum speed(mm/s) | 500 | 200 | 100 |
| Maximum acceleration(m/s2) | 15 | 15 | 15 |
| Rated thrust (N) | 20 | 15 | 15 |
| Peak thrust (N) | 81 | 60 | 60 |
| Rated current(Arms) | 0.6 | 0.6 | 0.6 |
| Peak current(Arms) | 2.5 | 2.5 | 2.5 |
| Thrust destiny(N/Arms) | 33 | 24 | 24 |
| inverse power constant(Vrms/m/s) | 11 | 8.1 | 8.1 |
| Resistance(Ω) | 43 | 33 | 33 |
| Inductance(mH) | 16 | 12 | 12 |
| Pole spacing(N-N )(mm) | 60 | 60 | 60 |
| Sensor signal | Differential ABZ phase | Differential ABZ phase | Differential ABZ phase |
| Sensor resolution(μm) | 0.05 | 0.05 | 0.05 |
| Bidirectional repetition accuracy(μm) | ±0.1 | ±0.1 | ±0.1 |
| Guiding type | Take the peristalsis cross roller guide rail system | ||
| Material | Aluminum, anodized black | ||
| Operating ambient temperature | 10-40℃ | ||
| Ambient humidity | 20-80% (no condensation) | ||
| Cable wire length | 3m | ||
| Driving and mechanical characteristics | θx | θy | θz |
| Effective stroke(°) | ±5 | ±5 | ±4,5 |
| Maximum speed (°/s) | 13.64 | 11.3 | 8.5 |
| Resolution(°) | 0.000682 | 0.000378 | 0.000282 |
| Repeat positioning accuracy(°) | 0.002 | 0.001 | 0.001 |
| Steering mechanism | Cross roller bearing | Cross roller bearing | Cross roller bearing |
| Transmission mechanism | Ball screw | Ball screw | Ball screw |
| Motor type | Five-phase step enters a motor | Five-phase step enters a motor | Five-phase step enters a motor |
| Material | Aluminum, anodized black | ||
| Operating ambient temperature | 10~40°C | ||
| Ambient humidity | 20-80% (no condensation) | ||
Outline dimension drawing
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty.
Q7: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%
