Zero Friction Linear Rotary Actuators Z Axis Force Control Platform Effective Stroke
Z-Axis Force Control Platform High Precision Zero Friction Effective Stroke 10-50mm
Z-axis force control platform High Precision Zero Friction Effective Stroke 10-50mm
Open loop control, soft landing fast
With high linear characteristics of current and pressure to achieve accurate pressure control
Z axis adopts air bearing to achieve zero friction and effectively improve the accuracy of force control
VF10 series Product specification:
| Specification parameters | VF10 | ||
| Driving and mechanical characteristics | VF1010 | VF1030 | VF1050 |
| Effective travel(mm) | Z | Z | Z |
| Effective stroke(mm) | 10 | 30 | 50 |
| Straightness(μm) | 3 | 3 | 3 |
| Maximum speed(mm/s ) | 50 | 200 | 300 |
| Maximum acceleration(G) | 15 | 15 | 15 |
| Z-axis load capacity(N) | 20 | 20 | 20 |
| moving weight(kg) | 0.3 | 0.35 | 0.4 |
| total weight(g) | 1.2 | 1.4 | 1.6 |
| Rated thrust (N/Nm) | 8.8 | ||
| Peak thrust (N/Nm) | 35 | ||
| Rated current(Arms) | 2.2 | ||
| Peak current(Arms) | 8.9 | ||
| Thrust destiny(N/Arms) | 3.9 | ||
| Reverse power constant(Vrms/m/s V/krpm) | 1.3 | ||
| Phase-to-phase resistance(Ω) | 1.5 | ||
| Phase-to-phase inductance(mH) | 0.3 | ||
| Pole spacing(mm) | 36 | ||
| Power specifications(VDC) | 24 | ||
| Orientation type | Gas bearing | ||
| Sensor signal | Phase difference AB | ||
| Sensor resolution(nm) | 50 | ||
| Two-way repeat precision(μm) | ±0.2 | ||
| Force control range(g) | 1-500 | ||
| Minimum force control value(g) | 1 | ||
| Force control accuracy | ±0.5 | ||
| main material | Aluminum, anodized black | ||
| Operating ambient temperature | 10~40°C | ||
| Ambient humidity | 20-80% (No condensation ) |
||
| Cable wire length | 5m | ||
Product dimension drawing:
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 5 workdays.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty.
Q7: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%
