Length 163mm 1000N Coil Linear Motor Magnet Linear Motor With Limited Space Equirements
Ironless Linear Motor Coil Unit Length 163mm Suitable For Applications With Limited Space And Big Force Requirements
Ironless Linear Motor Coil Unit Length 163mm Suitable For Applications With Limited Space And Big Force Requirements
| Parameter | Remarks | Symbol | Unit | EL150-03 | EL150-06 | EL150-09 | |||
| Winding Type | N | S | N | S | N | S | |||
| Motor type | 3 phases synchronous Ironless, 230Vacrms (320Vdc) | ||||||||
| Peak Force@20℃/s ↑ | Magnet@25℃ | Fp | N | 1000 | 1000 | 2000 | 2000 | 3000 | 3000 |
| Continuous Force | Coil@110℃ | Fc | N | 250 | 250 | 500 | 500 | 750 | 750 |
| Maximum Speed | 60V | Vmax | m/s | 1.6 | 3.2 | 1.6 | 3.2 | 1.6 | 3.2 |
| Motor Force Constant | Mount. Sfc.@20℃ | K | N/Arms | 177 | 84 | 177 | 84 | 177 | 84 |
| Motor Constant | Coils@25℃ | S | N²/W | 913 | 1826 | 2739 | |||
Electrical
| Peak Current | Magnet@25℃ | Ip | Arms | 5.6 | 11.9 | 11.3 | 23.8 | 16.9 | 35.7 |
| Continuous Current | Coil@110℃ | Ic | Arms | 1.5 | 3 | 3 | 6 | 4.5 | 9 |
| Back EMF | Phase-Phase peak | Bemf | V/M/S | 145 | 69 | 126 | 60 | 145 | 69 |
| Resistance Per Phase | Coil@25℃ | Rph | Ω | 11.5 | 2.84 | 5.75 | 1.45 | 3.8 | 0.95 |
| Induction Per Phase | I<0.63lp | Lph | mh | 34.5 | 8.5 | 17.3 | 4.4 | 11.4 | 2.9 |
| Electrical Time Constant | Coil@25℃ | τe | ms | 3 | 3 | 3 | 3 | 3 | 3 |
| Power Loss | All coils | Pc | W | 92 | 92 | 183 | 183 | 275 | 275 |
