90N Ironless Linear Motor EL44 Compact Linear Motor With Bigger Force
Ironless Linear MotorsForce Enhanced Version Of EL44, Compact Size, But Even Bigger Force
Ironless Linear Motors Force Enhanced Version Of EL44, Compact Size, But Even Bigger Force
| Performance | ||||||
| Parameter | Remarks | Symbol | Unit | EL44-03 | EL44-06 | EL44-09 |
| Winding Type | S | S | S | |||
| Motor type | 3 phases synchronous Ironless, 45Vacrms (60Vdc) | |||||
| Peak Force@20℃/s ↑ | Magnet@25℃ | Fp | N | 45 | 90 | 135 |
| Continuous Force | Coil@110℃ | Fc | N | 20 | 40 | 60 |
| Maximum Speed | 60V | Vmax | m/s | 5 | 5 | 5 |
| Motor Force Constant | Mount. Sfc.@20℃ | K | N/Arms | 12.4 | 12.4 | 12.4 |
| Motor Constant | Coils@25℃ | S | N²/W | 15 | 29 | 44 |
| Electrical | ||||||
| Peak Current | Magnet@25℃ | Ip | Arms | 3.6 | 7.3 | 11 |
| Continuous Current | Coil@110℃ | Ic | Arms | 1.6 | 3.2 | 4.8 |
| Back EMF | Phase-Phase peak | Bemf | V/M/S | 10 | 10 | 10 |
| Resistance Per Phase | Coil@25℃ | Rph | Ω | 3.5 | 1.75 | 1.17 |
| Induction Per Phase | I<0.63lp | Lph | mh | 1.2 | 0.6 | 0.4 |
| Electrical Time Constant | Coil@25℃ | τe | ms | 0.355 | 0.355 | 0.355 |
| Power Loss | All coils | Pc | W | 37 | 74 | 74 |
| Thermal | ||||||
| Thermal R. | Coils to mount. Sfc. | Rth | ºC/W | 2.35 | 1.175 | 0.5875 |
| Temp. Sensor | Temperature Cut-off | None (NTC/PTC can be customized) | ||||
| Mechanical | ||||||
| Coil Unit Weight | ex.cables | W | Kg | 0.05 | 0.1 | 0.15 |
| Coil Unit Length | ex.cables | L | mm | 49 | 97 | 145 |
| Motor Attraction Force | Rms@0A | Fa | N | 0 | 0 | 0 |
| Magnet Pitch | N-N | τ | mm(AWG) | 24 | 24 | 24 |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 4.5(3*0.3mm2) | ||
| Sensor Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | customizable | ||
| Cable life | Minimum | Cycles | ≥12,000,000 | |||
| Bending Radius Static | Minimum | mm | ≥4xφ | |||
| Bending Radius Dynamic | Minimum | mm | ≥7.5xφ | |||
Ironless linear motor dimension drawing:
