50nm Gas Bearing Linear Rotary Actuators 1.2kg Z Axis Control Platform
VF10 Z-axis force control platform Sensor resolution 50nm Gas bearing
VF10 Z-axis force control platform Sensor resolution 50nm Gas bearing
Open loop control, soft landing fast
With high linear characteristics of current and pressure to achieve accurate pressure control
Z axis adopts air bearing to achieve zero friction and effectively improve the accuracy of force control
VF10 series Product specification:
| Specification parameters | VF10 | ||
| Driving and mechanical characteristics | VF1010 | VF1030 | VF1050 |
| Effective travel(mm) | Z | Z | Z |
| Effective stroke(mm) | 10 | 30 | 50 |
| Straightness(μm) | 3 | 3 | 3 |
| Maximum speed(mm/s ) | 50 | 200 | 300 |
| Maximum acceleration(G) | 15 | 15 | 15 |
| Z-axis load capacity(N) | 20 | 20 | 20 |
| moving weight(kg) | 0.3 | 0.35 | 0.4 |
| total weight(g) | 1.2 | 1.4 | 1.6 |
| Rated thrust (N/Nm) | 8.8 | ||
| Peak thrust (N/Nm) | 35 | ||
| Rated current(Arms) | 2.2 | ||
| Peak current(Arms) | 8.9 | ||
| Thrust destiny(N/Arms) | 3.9 | ||
| Reverse power constant(Vrms/m/s V/krpm) | 1.3 | ||
| Phase-to-phase resistance(Ω) | 1.5 | ||
| Phase-to-phase inductance(mH) | 0.3 | ||
| Pole spacing(mm) | 36 | ||
| Power specifications(VDC) | 24 | ||
| Orientation type | Gas bearing | ||
| Sensor signal | Phase difference AB | ||
| Sensor resolution(nm) | 50 | ||
| Two-way repeat precision(μm) | ±0.2 | ||
| Force control range(g) | 1-500 | ||
| Minimum force control value(g) | 1 | ||
| Force control accuracy | ±0.5 | ||
| main material | Aluminum, anodized black | ||
| Operating ambient temperature | 10~40°C | ||
| Ambient humidity | 20-80% (No condensation ) |
||
| Cable wire length | 5m | ||
Product dimension drawing:
Shenzhen Haixincheng Technology Co., Ltd. is a high-tech enterprise focusing on the design, research and development, system integration and sales of encoders, motors, drives and motion control systems.
Haixincheng Technology has a strong service and support team composed of senior sales, research and development, application. Focus on the research and development of high-precision motion platform, committed to serving the field of high-precision motion control, providing micron, nanoscale positioning core components and motion control system. The main business areas include 3C automation, semiconductors, lithium equipment, precision machining and testing, collaborative robots, AGV logistics sorting, medical equipment and surgical robots and other industries and applications.
In addition to standard products, we can provide OEM customization, integrated solutions and value-added services according to customer requirements. The rapid development of the company at the same time, but also become many customers trust the preferred partner.
Corporate goal: To make sports easier
Service tenet: Thanksgiving, efficient, professional, innovative
