High Acceleration Speed Ironless Linear Motor 10N 3d Printer Linear Motor
High Acceleration Speed Ironless Linear Motor For 3D Printer Factory Direct Sale
High Acceleration Speed Ironless Linear Motor For 3D Printer Factory direct sale
Product advantages:
| Performance | |||||||
| Parameter | Remarks | Symbol | Unit | EL42-03 | EL42-06 | EL42-03S DHM | EL42-06S DHM |
| Winding Type | S | S | Hall Integrated | ||||
| Motor type | 3 phases synchronous Ironless, 45Vacrms (60Vdc) | ||||||
| Peak Force@20℃/s ↑ | Magnet@25℃ | Fp | N | 37 | 75 | 37 | 75 |
| Continuous Force | Coil@110℃ | Fc | N | 10 | 20 | 10 | 20 |
| Maximum Speed | 60V | Vmax | m/s | 5.4 | 5.4 | 5.4 | 5.4 |
| Motor Force Constant | Mount. Sfc.@20℃ | K | N/Arms | 11.5 | 11.5 | 11.5 | 11.5 |
| Motor Constant | Coils@25℃ | S | N²/W | 9 | 19 | 9 | 19 |
| Electrical | |||||||
| Peak Current | Magnet@25℃ | Ip | Arms | 3.2 | 6.5 | 3.2 | 6.5 |
| Continuous Current | Coil@110℃ | Ic | Arms | 0.88 | 1.76 | 0.88 | 1.76 |
| Back EMF | Phase-Phase peak | Bemf | V/M/S | 9 | 9 | 9 | 9 |
| Resistance Per Phase | Coil@25℃ | Rph | Ω | 4.75 | 2.375 | 4.75 | 2.375 |
| Induction Per Phase | I<0.63lp | Lph | mh | 0.8 | 0.4 | 0.8 | 0.4 |
| Electrical Time Constant | Coil@25℃ | τe | ms | 0.16 | 0.16 | 0.16 | 0.16 |
| Power Loss | All coils | Pc | W | 14.8 | 29.6 | 14.8 | 29.6 |
| Thermal | |||||||
| Thermal R. | Coils to mount. Sfc. | Rth | ºC/W | 3.58 | 1.79 | 3.58 | 1.79 |
| Temp. Sensor | Temperature Cut-off | None (NTC/PTC can be customized) | |||||
| Mechanical | |||||||
| Coil Unit Weight | ex.cables | W | Kg | 0.03 | 0.06 | 0.03 | 0.06 |
| Coil Unit Length | ex.cables | L | mm | 34 | 67 | 34 | 67 |
| Motor Attraction Force | Rms@0A | Fa | N | 0 | 0 | 0 | 0 |
| Magnet Pitch | N-N | τ | mm(AWG) | 16.5 | 16.5 | 16.5 | 16.5 |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 4.5(3*0.3mm2) | 5.6(3*0.3mm2+5*0.08) | ||
| Sensor Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | customizable | |||
| Cable life | Minimum | Cycles | ≥12,000,000 | ||||
| Bending Radius Static | Minimum | mm | ≥4xφ | ||||
| Bending Radius Dynamic | Minimum | mm | ≥7.5xφ | ||||
Product dimension drawing:
Factory environment
Application area
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 5 workdays.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty.
Q7: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%
