Fast Response High Precision High Torque Motor Compact Structure Easy Maintenance
High Torque Motor Fast Response High Precision Compact Structure Easy Maintenance
TBSM series sine wave brushless torque motor can be directly embedded in the using equipment by bearing the rotor in the joint of cooperative robot, medical robot, guidance system, optical system and other kinds of automation equipment. TBSM series products are suitable for the motor requirements, small size, compact structure, light weight, low inertia, high power output applications.
HXC has the core technology, process and intellectual property to design and manufacture all kinds of direct drive motor products. Combined with its efficient and cost-effective joint research and development capabilities, we can customize high-performance special motors for collaborative robots for you.
Brushless torque motor product features:
1. Patent technology products with independent intellectual property rights
2. Very low distortion sine wave counter potential waveform
3. Can run at very low speed, wide range of speed regulation ratio up to 3000000:1
4. Ultra-low torque fluctuation, all products torque fluctuation ≤ 3%
5. Can accept special model custom design
6. NdFeB material, stable operation in high temperature environment, high power density
| Type | Peak Standstill | Max.no-load | Cont Standstill | Rated power | resistance | Back EMF Coefficient |
Torque Coefficient |
Moment of inertia |
weight | |||||
| Torque | Current | Voltage | Torque | Current | Voltage | Torque | speed | |||||||
| Nm | A | V | r/min | Nm | A | V | Nm | r/min | Q | v/rpm | Nm/A | Kg.m²*10⁵ | Kg | |
| ≥ | ±10% | ±10% | ±10% | ≥ | ±10% | ±10% | ±5% | ±10% | ±10% | ±10% | ||||
| TBSM129-13A26 | 9.53 | 57 | 48 | 2600 | 3.7 | 22 | 2.8 | 2.39 | 2502 | 0.13 | 0.0183 | 0.17 | 59 | 1.2 |
| TBSM129-13D27 | 19.16 | 57 | 100 | 2700 | 3.5 | 10.5 | 5.5 | 2.3 | 2604 | 0.52 | 0.0369 | 0.34 | 59 | 1.2 |
| TBSM129-13A20 | 9.95 | 45 | 48 | 1970 | 3.7 | 16.5 | 3.7 | 2.37 | 1872 | 0.22 | 0.0241 | 0.22 | 59 | 1.2 |
| TBSM129-13A10 | 19.91 | 45 | 48 | 985 | 3.5 | 8 | 7.3 | 2.3 | 887 | 0.91 | 0.0482 | 0.44 | 59 | 1.2 |
| TBSM129-13A29 | 10 | 66.5 | 48 | 2900 | 3.5 | 23.3 | 2.38 | 2.3 | 2700 | 0.11 | 0.165 | 0.15 | 59 | 1.2 |
| TBSM129-20D15 | 32.76 | 56 | 100 | 1550 | 5.4 | 9.3 | 7.9 | 3.54 | 1471 | 0.84 | 0.0642 | 0.58 | 92 | 1.6 |
| TBSM129-20A13 | 19.1 | 57 | 48 | 1300 | 5.4 | 16 | 4.3 | 3.48 | 1224 | 0.27 | 0.0365 | 0.34 | 92 | 1.6 |
| TBSM129-20A20 | 10 | 44.8 | 48 | 1950 | 5.4 | 24.2 | 3.05 | 3.5 | 1800 | 0.125 | 0.024 | 0.22 | 92 | 1.6 |
| TBSM129-20A24 | 10 | 56 | 48 | 2400 | 5.4 | 30 | 2.4 | 3.5 | 2250 | 0.085 | 0.0198 | 0.18 | 92 | 1.6 |
| TBSM129-40D18 | 28.75 | 57 | 100 | 1800 | 9.1 | 18 | 4.1 | 5.9 | 1752 | 0.23 | 0.0553 | 0.5 | 165 | 2.8 |
| TBSM129-40A13 | 19 | 57 | 48 | 1300 | 9 | 27 | 2.7 | 5.85 | 1253 | 0.1 | 0.0365 | 0.33 | 165 | 2.8 |
| TBSM129-40F15 | 30 | 62 | 80 | 1500 | 9 | 18.6 | 4.0 | 5.85 | 1400 | 0.215 | 0.533 | 0.484 | 165 | 2.8 |
| TBSM129-55A10 | 25.99 | 57 | 48 | 950 | 11.4 | 25 | 3.1 | 7.41 | 911 | 0.12 | 0.05 | 0.46 | 221 | 4 |
| TBSM129-55A06 | 39.23 | 57 | 48 | 630 | 11.7 | 17 | 4.8 | 7.60 | 589 | 0.28 | 0.0754 | 0.69 | 221 | 4 |
| TBSM129-55D10 | 23.5 | 26 | 100 | 1000 | 11.8 | 13 | 6.4 | 7.67 | 959 | 0.49 | 0.0995 | 0.91 | 221 | 4 |
| TBSM129-55D05 | 27.5 | 15 | 100 | 495 | 11.9 | 6.5 | 13.4 | 7.73 | 452 | 2.06 | 0.201 | 1.83 | 221 | 4 |
TBSM129 Sectional outline drawing of series sine wave brushless DC torque motor
Brushless torque motor working temperature -40℃~85℃
Brushless torque motor application (exoskeleton,medical equipment,aerospace,cobot arm)
A variety of modes of transportation
