U Channel Ironless High Speed Linear Motor , 3 Phase Brushless Linear Servo Motor
Factory U Channel Ironless High Speed Linear Motor 3 Phase Brushless Linear Servo Motor
1. No attraction , no need to deal with attraction when installing ironless linear motor, so it is easy to install.
2. No slot effect, easy to achieve more stable motion to achieve higher accuracy.
3. Spliced stator, stroke can be extended.
4. No iron core means higher acceleration and deceleration.
| Performance | |||||||
| Parameter | Remarks | Symbol | Unit | EL42-03 | EL42-06 | EL42-03S DHM | EL42-06S DHM |
| Winding Type | S | S | Hall Integrated | ||||
| Motor type | 3 phases synchronous Ironless, 45Vacrms (60Vdc) | ||||||
| Peak Force@20℃/s ↑ | Magnet@25℃ | Fp | N | 37 | 75 | 37 | 75 |
| Continuous Force | Coil@110℃ | Fc | N | 10 | 20 | 10 | 20 |
| Maximum Speed | 60V | Vmax | m/s | 5.4 | 5.4 | 5.4 | 5.4 |
| Motor Force Constant | Mount. Sfc.@20℃ | K | N/Arms | 11.5 | 11.5 | 11.5 | 11.5 |
| Motor Constant | Coils@25℃ | S | N²/W | 9 | 19 | 9 | 19 |
| Electrical | |||||||
| Peak Current | Magnet@25℃ | Ip | Arms | 3.2 | 6.5 | 3.2 | 6.5 |
| Continuous Current | Coil@110℃ | Ic | Arms | 0.88 | 1.76 | 0.88 | 1.76 |
| Back EMF | Phase-Phase peak | Bemf | V/M/S | 9 | 9 | 9 | 9 |
| Resistance Per Phase | Coil@25℃ | Rph | Ω | 4.75 | 2.375 | 4.75 | 2.375 |
| Induction Per Phase | I<0.63lp | Lph | mh | 0.8 | 0.4 | 0.8 | 0.4 |
| Electrical Time Constant | Coil@25℃ | τe | ms | 0.16 | 0.16 | 0.16 | 0.16 |
| Power Loss | All coils | Pc | W | 14.8 | 29.6 | 14.8 | 29.6 |
| Thermal | |||||||
| Thermal R. | Coils to mount. Sfc. | Rth | ºC/W | 3.58 | 1.79 | 3.58 | 1.79 |
| Temp. Sensor | Temperature Cut-off | None (NTC/PTC can be customized) | |||||
| Mechanical | |||||||
| Coil Unit Weight | ex.cables | W | Kg | 0.03 | 0.06 | 0.03 | 0.06 |
| Coil Unit Length | ex.cables | L | mm | 34 | 67 | 34 | 67 |
| Motor Attraction Force | Rms@0A | Fa | N | 0 | 0 | 0 | 0 |
| Magnet Pitch | N-N | τ | mm(AWG) | 16.5 | 16.5 | 16.5 | 16.5 |
| Power Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | 4.5(3*0.3mm2) | 5.6(3*0.3mm2+5*0.08) | ||
| Sensor Cable Type | length 0.5m(3m,5m,10m optional) | Diameter | mm(mm2) | customizable | |||
| Cable life | Minimum | Cycles | ≥12,000,000 | ||||
| Bending Radius Static | Minimum | mm | ≥4xφ | ||||
| Bending Radius Dynamic | Minimum | mm | ≥7.5xφ | ||||
3 phase linear motor dimension drawing:
FAQ:
Q1. Can I have a sample order?
A: yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Sample needs 5-7 workdays.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: By express or air or sea .
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Q8: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less than 0.2%
Q9:How is your quality control?
A: Our professional QC will check the quality during production and carry out quality test before shipment.
